Downstream Components
PTi provides a selection of shears, stacking systems and sheet winding options designed to accommodate a comprehensive range of sheet production applications. From robotic style stackers (single or dual station); to fully automatic winders, PTi offers a single source solution for your sheet handling needs.
Cantilevered Winders
Common in the industry, the cantilevered winder is typically used for sheet widths of 60" and below, with a roll diameter of 40" or less. It is ideal for rolls that are being stored or palleted. It offers a cost-effective approach and ease of use as the shaft does not need to be manually handled/lifted. Rolls are removed with a manual lift cart.
Supported Cantilevered Winders
PTi Supported Cantilevered Winders feature an end-supported cart design for larger applications, accommodating sheet widths up to 84" (2130 mm) and roll diameters up to 48" (1220 mm). Push-button roll unloading further simplifies finished-roll handling.
Features
-
Precision Web Control – Supports accurate web tracking and tension control.
-
Integrated Nip Rolls – Driven nip rollers and guide idlers support controlled sheet handling.
-
Static Elimination – Helps reduce static buildup during winding.
-
Task Lighting – Improves operator visibility during web transfers.
-
Safety Guarding – Interlocked doors and caging restrict access during operation.
-
Intuitive Controls – Provides straightforward operator control and ease of use.
-
Heavy-Duty Construction – Robust framework supports reliable, precision winding.
-
Push-Button Roll Unloading – Simplifies finished roll removal and handling. (Supported Style Only)
.jpeg)
OFFERING YOU THE BEST SOLUTION FOR YOUR EXTRUSION LINE
Processing Technologies International (PTi) is a global leader in high-performance sheet extrusion machinery. Engineered to exact standards, PTi systems feature innovative design solutions that deliver superior equipment performance and consistently produce sheet goods that meet the industry’s highest quality standards.
PTi offers a comprehensive range of products and services designed to support today’s sheet producers and the evolving demands of the future. While this overview highlights many available configurations and capabilities, it represents only a portion of the customized extrusion solutions PTi provides for a wide variety of applications.
